[WIP] Improving usefulness of Foil

[Agetian]

That's not my quote!

Hehe sorry, got that corrected. Looks like I overshot a bit when killing text from the quotes.

@ Diogenes: Yeah, makes sense, and no problem!

- Agetian

[Agetian]

Starting with r22352, edition-specific foiling is implemented in code. In particular, if the MTG edition definition file specifies Foil=NotSupported, no cards from this set will be foiled. If the definition file specifies Foil=OldStyle, cards from this edition will be foiled with foil images from the "sprite_old_foils.png" sheet if it is available (if it does not exist, "sprite_foils.png" will be used). If the definition file specifies Foil=NewStyle, cards from this edition will be foiled with foil images from the standard default "sprite_foils.png" sheet.

Starting with r22353, if an edition file does not contain the Foil line, it defaults to modern (NewStyle) foils.

Now, I've tried to compile a list of information about which editions should use which foil style, I'm really unsure about some of them. Can you please check and see if I'm right or if you'd need any changes? Really unsure about 6th edition by the way, historically it fits into the time frame after the foils have already been introduced, but I'm not sure if the set featured foils... (I think so, but you never know).

Code: Select all

        1998-11     Anthologies - N/A
        2001-12     Deckmasters - N/A
        1995-08     Renaissance - N/A
        1996-07     Rivals Quick Start Set - N/A
        1996-11     Multiverse Gift Box - N/A
10E     2007-07-14  Tenth Edition - MODERN
1E      1993-08-05  Limited Edition Alpha - N/A
2E      1993-10-01  Limited Edition Beta - N/A
2U      1993-12-01  Unlimited Edition - N/A
3E      1994-04-01  Revised Edition - N/A
4E      1995-04-01  Fourth Edition - N/A
5DN     2004-06-04  Fifth Dawn - MODERN
5E      1997-03-24  Fifth Edition - N/A
6E      1999-04-28  Classic Sixth Edition - OLD STYLE
7E      2001-04-11  Seventh Edition - N/A
8ED     2003-07-28  Eighth Edition - MODERN
9ED     2005-07-29  Ninth Edition - MODERN
AL      1996-06-10  Alliances - N/A
ALA     2008-10-03  Shards of Alara - MODERN
AN      1993-12-01  Arabian Nights - N/A
AP      2001-06-04  Apocalypse - OLD STYLE
AQ      1994-03-01  Antiquities - N/A
ARB     2009-04-30  Alara Reborn - MODERN
ARC     2010-06-18  Archenemy - MODERN
ASTRAL  1997-04     Astral - N/A
AVR     2012-05-04  Avacyn Restored - MODERN
BD      2000-12     Beatdown Box Set - OLD STYLE (?)
BOK     2005-02-04  Betrayers of Kamigawa - MODERN
BR      1999-11-12  Battle Royale Box Set - OLD STYLE (?)
CG      1999-06-07  Urza's Destiny - OLD STYLE
CH      1995-07     Chronicles - N/A
CHK     2004-10-01  Champions of Kamigawa - MODERN
CM1     2012-11-02  Commander's Arsenal - MODERN
CMD     2011-06-17  Magic: The Gathering-Commander - MODERN
CON     2009-02-06  Conflux - MODERN
CSP     2006-07-21  Coldsnap - MODERN
DD2     2008-11-07  Duel Decks: Jace vs. Chandra - MODERN
DDC     2009-04-10  Duel Decks: Divine vs. Demonic - MODERN
DDD     2009-10-30  Duel Decks: Garruk vs. Liliana - MODERN
DDE     2010-03-19  Duel Decks: Phyrexia vs. the Coalition - MODERN
DDF     2010-09-03  Duel Decks: Elspeth vs. Tezzeret - MODERN
DDG     2011-04-01  Duel Decks: Knights vs. Dragons - MODERN
DDH     2011-09-02  Duel Decks: Ajani vs. Nicol Bolas - MODERN
DDI     2012-03-30  Duel Decks: Venser vs. Koth - MODERN
DDJ     2012-09-07  Duel Decks: Izzet vs. Golgari - MODERN
DDK     2013-03-15  Duel Decks: Sorin vs. Tibalt - MODERN
DGM     2013-05-03  Dragon's Maze - MODERN
DIS     2006-05-05  Dissension - MODERN
DK      1994-08-01  The Dark - N/A
DKA     2012-02-03  Dark Ascension - MODERN
DRB     2008-08-29  From the Vault: Dragons - MODERN
DREAM   2001-06     Dreamcast - N/A
DST     2004-02-06  Darksteel - MODERN
EVE     2008-07-25  Eventide - MODERN
EVG     2007-11-16  Duel Decks: Elves vs. Goblins - MODERN
EX      1998-06-15  Exodus - N/A
FE      1994-11-01  Fallen Empires - N/A
FUT     2007-05-04  Future Sight - MODERN
GPT     2006-02-03  Guildpact - MODERN
GTC     2013-02-01  Gatecrash - MODERN
GU      1999-02-15  Urza's Legacy - OLD STYLE
H09     2009-11-20  Premium Deck Series: Slivers - MODERN
HM      1995-10-01  Homelands - N/A
HOP     2009-09-04  Planechase - MODERN
IA      1995-06-01  Ice Age - N/A
IN      2000-10-02  Invasion - OLD STYLE
ISD     2011-09-30  Innistrad - MODERN
JUD     2002-05-27  Judgment - OLD STYLE
LE      1994-06-01  Legends - N/A
LGN     2003-02-03  Legions - OLD STYLE
LRW     2007-10-12  Lorwyn - MODERN
M10     2009-07-17  Magic 2010 - MODERN
M11     2010-07-16  Magic 2011 - MODERN
M12     2011-07-15  Magic 2012 - MODERN
M13     2012-07-13  Magic 2013 - MODERN
MBS     2011-02-04  Mirrodin Besieged - MODERN
ME2     2008-09-22  Masters Edition II - MODERN
ME3     2009-09-07  Masters Edition III - MODERN
ME4     2011-01-10  Masters Edition IV - MODERN
MED     2007-09-10  Masters Edition - MODERN
MI      1996-10-08  Mirage - N/A
MM      1999-10-04  Mercadian Masques - OLD STYLE
MOR     2008-02-01  Morningtide - MODERN
MRD     2003-10-02  Mirrodin - MODERN
NE      2000-02-14  Nemesis - OLD STYLE
NPH     2011-05-13  New Phyrexia - MODERN
OD      2001-10-01  Odyssey - OLD STYLE
ONS     2002-10-07  Onslaught - OLD STYLE
P2      1998-06     Portal Second Age - N/A
P3      1999-07     Starter 1999 - OLD STYLE (???)
P4      2000-07     Starter 2000 - OLD STYLE (???)
PC2     2012-06-01  Planechase 2012 Edition - MODERN
PD2     2010-11-19  Premium Deck Series: Fire and Lightning - MODERN
PD3     2011-11-18  Premium Deck Series: Graveborn - MODERN
PK      1999-05     Portal Three Kingdoms - OLD STYLE
PLC     2007-02-02  Planar Chaos - MODERN
PO      1997-06     Portal - N/A
PPR                 Promo set for Gatherer - MODERN (???)
PR      2000-06-05  Prophecy - OLD STYLE
PS      2001-02-05  Planeshift - OLD STYLE
RAV     2005-10-07  Ravnica: City of Guilds - MODERN
ROE     2010-04-23  Rise of the Eldrazi - MODERN
RTR     2012-10-05  Return to Ravnica - MODERN
SCG     2003-05-26  Scourge - OLD STYLE
SHM     2008-05-02  Shadowmoor - MODERN
SOK     2005-06-03  Saviors of Kamigawa - MODERN
SOM     2010-10-01  Scars of Mirrodin - MODERN
ST      1998-03-02  Stronghold - N/A
TE      1997-10-14  Tempest - N/A
TOR     2002-02-04  Torment - OLD STYLE
TSB     2006-10-06  Time Spiral "Timeshifted" - MODERN (?)
TSP     2006-10-06  Time Spiral - MODERN
UG      1998-08-17  Unglued - N/A
UNH     2004-11-19  Unhinged - MODERN
UZ      1998-10-12  Urza's Saga - N/A (?)
V09     2009-08-28  From the Vault: Exiled - MODERN
V10     2010-08-27  From the Vault: Relics - MODERN
V11     2011-08-26  From the Vault: Legends - MODERN
V12     2012-08-31  From the Vault: Realms - MODERN
VAN                 Vanguard - N/A (?)
VI      1997-02-03  Visions - N/A
WL      1997-06-09  Weatherlight - N/A
WWK     2010-02-05  Worldwake - MODERN
ZEN     2009-10-02  Zendikar - MODERN


Thanks in advance for help!

- Agetian

[Max mtg]

TSB - does it use old foiling style? (for being not-modern)

[Agetian]

TSB - does it use old foiling style? (for being not-modern)

Umm that's a very interesting question! I've found this page with an example TSB foil, but I'm not sure if it's a real actual photo or if it's just modded to look foil:
http://www.trollandtoad.com/p385103.html
Here's another one on eBay:
http://www.ebay.com/itm/MTG-Magic-TIME- ... 0039143369
Anyhow, if it is real, it looks like the modern style foiling is used on TSB foils... :\

By the way, it looks like 6th edition indeed had foils (and black-bordered at that):
http://static.trollandtoad.com/products ... 123514.jpg

- Agetian

[friarsol]

By the way, it looks like 6th edition indeed had foils (and black-bordered at that):
http://static.trollandtoad.com/products ... 123514.jpg

The link I posted the other day said that explicitly: "All foil cards are black-bordered, even those from core sets, except those from Unhinged which are silver-bordered."

[Agetian]

@ friarsol: Yep, I remember that, I was just surprised to see 6th edition foils at all for some reason Not sure why.

- Agetian

[lsdmaster]

@ friarsol: Yep, I remember that, I was just surprised to see 6th edition foils at all for some reason Not sure why.

- Agetian

Because they're promos (like foil Duress from Urza's Saga). 6th edition boosters don't contain foil cards.

http://www.magiclibrarities.net/sets-sixth-edition.html
http://www.magiclibrarities.net/5-rarit ... -2000.html
http://www.magiclibrarities.net/72-rari ... -2000.html

[Agetian]

@ lsdmaster: Thanks for the info!

Is there any source for complete information about which editions have boosters with foils and which don't?

- Agetian

[Agetian]

I'm trying to make the foil cards appear foiled in the card picture panel during the match (and possibly the deck editor), but for some reason I'm encountering a rather strange issue I can't crack on my own yet due to my lack of experience with the graphics subsystem in Java:

if I modify CardPicturePanel.setImage and do something like this:

Code: Select all

        if (image != this.currentImage) {
            this.currentImage = image;
            this.panel.setImage(image);

            /* INSERTED CODE HERE */
            if (foilIndex > 0) {
                final String fl = String.format("foil%02d", foilIndex);
                final int z = Math.round(this.getWidth() * CardPanel.getBorderSize());
                CardFaceSymbols.drawOther(this.panel.getGraphics(), fl, z, z, this.panel.getWidth() - (2 * z),
                        this.panel.getHeight() - (2 * z));
            }
            /* INSERTED CODE ENDS HERE */

            this.panel.repaint();
        }


the foil is not drawn. Well, it's kind of drawn (sometimes I can see it for a small fraction of a second when the card is displayed), but then it immediately disappears, and most of the time even that is not noticeable. It looks like the drawn foil overlay gets discarded during repaint or something like that.

I also tried to draw directly on the image but since the images are loaded from cache, it's not possible because the foil gets hard-drawn onto the surface of the image until the game is restarted, which is completely undesirable. What *is* possible to do is make a copy of the image from the cache and set the card picture panel to that, but that might waste the CPU cycles making the copy every time a new card is displayed in the card picture panel.

Can someone please advise me what the best approach would be here?

By the way, another potential issue is that even if I get the code above to work, it'll only work during the match, but not in the deck editor. The problem is that the deck editor operates with InventoryItems, while the match operates with Cards, and InventoryItem has no clue about whether its particular card instance (e.g. in the deck) is foil or not. Not sure if displaying a foiled picture would even be necessary in the deck editor (maybe a simple flag indicating it's a foil card would suffice), but do you have any suggestions for this one as well?

Thanks in advance for any help!

- Agetian

[Max mtg]

foilInBoosters - should be not just true/false, but some kind of foil rate.
Say, common editions have 1/5 foil ratio, while MMA has 1/1. Editions that have no foils may use just any ratio, it won't be considered in booster generator

[Agetian]

foilInBoosters - should be not just true/false, but some kind of foil rate.
Say, common editions have 1/5 foil ratio, while MMA has 1/1. Editions that have no foils may use just any ratio, it won't be considered in booster generator

I changed it to an int value that represents a chance (out of 100%) of a foil appearing in a booster - so, 1/5 would be 20% etc. Thanks for the advice! By the way, is there some resource that we can gather information like that for all the sets in Magic?

- Agetian

[lsdmaster]

@ lsdmaster: Thanks for the info!

Is there any source for complete information about which editions have boosters with foils and which don't?

- Agetian

This site has all the info you need. Just check the expansion (for instance 7th edition says "350 foil black-border cards"):

http://www.magiclibrarities.net/sets.html

[Agetian]

@ lsdmaster: Thanks for the info!

Ok, starting with r22363, the foil cards will show up as foil in the card picture panel during the match (but not in the deck editor). Still don't quite like the solution I've come up with, but it's the only thing I was able to work out after many hours of experiments - basically, if a card is non-foil, it's drawn the old fashioned way so there's no resource overhead; if it's foil, a temporary copy of the image from the cache is made, which is then foiled and displayed in the card picture panel. I've checked the memory usage and confirmed that there is no resource leak caused by that. If I come up with something better I'll change the implementation.

Still no idea how to work foiled picture in the card panel into the deck editor for now.

- Agetian

[Agetian]

Here's a test sprite sheet for the old-style foils (based on the original one currently in Forge), I didn't commit it to SVN yet because I'm not sure how it may behave on card pictures coming from different sources (given that it has 'holes' in the places where the card picture and the card text should be). That being said, it works pretty well on my high quality pictures coming from CCGHQ. Please see how it works for you.

- Agetian

[Agetian]

Here's a good question: what do you think would be an easy enough and viable way to differentiate between foil and non-foil cards in the deck editor? I thought maybe indicating foil with a simple marker, like (*) next to the name, would suffice, but I'm not sure if it's possible and worth it to implement it like that.

- Agetian
